Flexo Printing Machine for Paper Cups

The Flexo Printing Machine for Paper Cups is designed for high-quality printing on paper cup stock, delivering clear patterns and consistent print quality. Featuring a shaftless unwinding unit and corona treatment system, it supports efficient material handling and improved ink adhesion for paper cup stock and other paper packaging applications.

Max. Mechanical Speed

250 m/min

Print Width

250-3000mm

Colors

4-10 Colors

Printing Precision

±0.10mm

Ink

Water base ink

Drive System

Central drum with Gear drive

Introduction

Designed for high-quality printing on paper cup stock, this Flexo Printing Machine for Paper Cups delivers clear patterns and consistent print quality for disposable cup and paper packaging production. The shaftless unwinding unit simplifies roll handling, while the corona treatment system helps improve surface wettability and ink adhesion when required. Combined with a central drum gear drive system, the machine provides stable operation and reliable printing performance.

High-quality printing for paper cup stock.

Shaftless unwinding for convenient roll handling.

Corona treatment to support improved ink adhesion.

Stable printing performance for paper packaging applications.

❮

▶

❯

Why Choose This Machine?

Stable Production. Improved Ink Adhesion. Consistent Print Quality

Efficient Production

With a maximum machine speed of 250 m/min, the machine supports efficient printing for paper cup stock and other suitable paper packaging materials.

Convenient Material Handling

The shaftless unwinding unit simplifies roll loading and handling, helping operators manage paper rolls efficiently during production.

Excellent Printing Quality

With printing precision of ±0.1mm and support for 4–10 colors, the machine helps deliver accurate registration and clear multicolor designs.

Improved Ink Adhesion

The integrated corona treatment system helps improve surface wettability and ink adhesion on compatible substrates, supporting consistent printing results.

Technical Specifications

Model	CHCI6-600J-Z	CHCI6-800J-Z	CHCI6-1000J-Z	CHCI6-1200J-Z	CHCI6-1400J-Z	CHCI6-1600J-Z
Max. Web Width	650mm	850mm	1050mm	1250mm	1450mm	1650mm
Max. Printing Width	600mm	800mm	1000mm	1200mm	1400mm	1600mm
Max. Mechanical Speed	250m/min
Max. Printing Speed	200m/min
Max. Unwind/ Rewind Dia.	Φ1200mm/Φ1500mm
Drive Type	Central drum with Gear drive
Printing Length (repeat)	350-900mm
Electrical Supply	Voltage 380V. 50 HZ.3PH or to be specified
Ink	Water base ink or solvent ink
Range of Substrates	Paper, Paper bag, Paper cup,Paper box
Photopolymer plate	To be specified

Product Samples

Trusted by Customers Across the Globe

Our machines are esported to more than 80 countries and regions, trusted by thousands of customers worldwide

Countries & Regions

2000

Happy Customers

Years Experience

Aftersales Support

Frequently Asked Questions

What materials can this Flexo Printing Machine for Paper Cups print on?

This machine is designed primarily for paper cup stock and can also be used for other suitable paper packaging materials, depending on the material specifications and machine configuration.

What is the maximum printing speed of this paper cup flexo printing machine?

The machine has a maximum speed of 250 m/min, supporting efficient roll-to-roll printing for paper cup stock.

How many colors does this machine support?

The machine supports 4–10 colors, allowing different configurations for logos, text, decorative patterns, and multicolor cup designs.

What is the function of the shaftless unwinding unit?

The shaftless unwinding unit allows paper rolls to be loaded and secured without a conventional winding shaft, helping simplify roll changes and improve material handling efficiency.

How does corona treatment improve printing quality?

Corona treatment modifies the surface properties of compatible materials to improve wettability and ink adhesion. Its effectiveness depends on the substrate, surface condition, and ink system.

What type of ink does this paper cup flexo printing machine use?

The machine uses water-based ink, which can be suitable for paper cup stock printing when the ink formulation meets the substrate, drying, and intended-use requirements. For cups intended for food and beverage contact, the ink and printing process should comply with applicable food-contact regulations.
